Adult Pelvis with Organs for X-Ray CT, MRI

Task trainer
Radiology
Main product
Medicine

The Adult Pelvis with Organs Phantom is designed based on an average adult human (male). The synthetic bones used in this phantom are made out of our patented material, which is best suited for the X-Ray/CT, and MRI imaging applications.

Price on request

Available in Spain, Portugal and Andorra · delivery time given in the proposal

Download data sheet

Downloadable data sheet — features, specifications and delivery time, in PDF.

Need a technical report? Ask us for it and we'll send it within 24 h →

Catalogue

Description

What this equipment is and what it's designed for.

The Adult Pelvis with Organs Phantom is designed based on an average adult human (male). It is made out of realistic patented bone material that is suitable for X-RAY CT and MRI imaging applications. It can be used as a tool to conduct medical imaging research, radiology training , testing, and calibration purposes. This product can be further customized to match our client’s specific requirements.

In terms of MRI applications, the phantom tissues have realistic T2 relaxation time values, which makes this product the best fit for any T2-weighted MRI imaging methods. Very good results can also be achieved with proton-density imaging methods. The phantom can still be imaged with T1-weighted methods, but the T1 values are less realistic, and they are within the range of about 100 ms.

The bones will consist of a realistic three-layered structure with inner porosity, which can be adjusted according to the requirement of the particular project. The phantom can also be customized in size and shape (i.e. based on any individual’s CT scan).

Product IMages Custom Fat Layer Product Designs Videos

Note: By default, the phantom comes in a translucent amber appearance. The skin feature can be included upon request.

Note: This is a custom fat layer which can be added upon request. With the addition of this fat layer, BMI of the phantom was increased to 28.

adult-pelvis-w-prostate-400300 adult-pelvis-w-prostate4 adult-pelvis-w-prostate3 adult-pelvis-w-prostate2

Knowledge

What you learn

Task trainer modality. The competencies this equipment trains, in the language of the training plan.

Centre the pelvis and check the symmetry of the iliac wings.
Position and centre the specimen for each projection or slice plane.
Choose the radiographic technique and check its effect on the image.
Adjust the CT protocol and assess the result on the reconstructions.
Try out MRI sequences and compare the contrast between tissues.
Apply the image quality criteria and repeat the acquisition when they are not met.

Related procedures: MRI · Tomography · X-ray

Knowledge

Cases and pathologies

The clinical scenarios that can be simulated with this equipment.

X-ray and CT of the bony pelvis.
Study of the pelvic structures on the image.
Training in pelvis and hip positioning.
Acceptance testing of a unit or validation of a new protocol.
Training radiographers and residents without exposing any patient.

Catalogue

Features and what's included

What the equipment does and what comes in the box, as described by the manufacturer.

Features

Pelvic organs differentiated from the bony structure.
Imaging response equivalent to human tissue in X-ray, CT and MRI.
Differentiated internal anatomy, not a homogeneous block.
No ferromagnetic components: it can enter the MRI room.
It can be scanned as often as needed and exposes nobody to radiation.

Includes

User Manual/Assembly Instructions
2-Year Warranty & Unlimited Customer Service
Size: 14 x 10 x 16 Inches
Size: 32 x 23 x 13 Inches
