Adult Breast for X-Ray CT, MRI

Task trainer
Radiology
Main product
Medicine

The Adult Breast (Complex) for X-Ray CT, US, MRI is a life-sized representation of a female breast, meticulously crafted to reflect typical anatomical features.

Price on request

Available in Spain, Portugal and Andorra · delivery time given in the proposal

Download data sheet

Downloadable data sheet — features, specifications and delivery time, in PDF.

Need a technical report? Ask us for it and we'll send it within 24 h →

Catalogue

Description

What this equipment is and what it's designed for.

The Adult Breast (Complex) for X-Ray CT, US, MRI is a realistic phantom that is designed based on the average anatomy of a female breast, and it contains all the essential bones and organs. This phantom is compatible with X-Ray/CT, US, and MRI imaging, which makes it an ideal tool to study, research, and test medical imaging devices .

In terms of MRI applications, the phantom tissues have realistic T2 relaxation time values, which makes this product the best fit for any T2-weighted MRI imaging methods. Very good results can also be achieved with Proton Density imaging methods.

The phantom can be still imaged with T1-weighted methods, but the T1 values are less realistic, and they are within the range of about 100 ms.

This phantom is a life-size female breast phantom with all bony and major organ structures. BT-A01 can be used to study several diagnostic procedures under X-Ray/CT, US & MRI in different orientation and positioning techniques.

Upon request, this product can be customized to different pathologies as well as for specific training applications.

Note: By default, the phantom comes in a translucent amber appearance. The skin feature can be included upon request.

All standard phantoms are coated with a protective layer of the harder urethane rubber to offer enhanced appearance and safeguard the phantom from any scratches when handled without care. This coated layer also provides a glossy finish and slightly changes the hardness of the phantom. The Hardness [Shore 00] for the ‘Body Tissue’ mentioned above is measured without the coat layer. The coat will increase the hardness by approximately 30 points meaning that if the body tissue hardness is OO 35, the coated body tissue will be OO 65.

Knowledge

What you learn

Task trainer modality. The competencies this equipment trains, in the language of the training plan.

Position and compress the breast to obtain the correct projection.
Position and centre the specimen for each projection or slice plane.
Choose the radiographic technique and check its effect on the image.
Adjust the CT protocol and assess the result on the reconstructions.
Try out MRI sequences and compare the contrast between tissues.
Apply the image quality criteria and repeat the acquisition when they are not met.

Related procedures: Mammary · MRI · Tomography · X-ray

Knowledge

Cases and pathologies

The clinical scenarios that can be simulated with this equipment.

Mammographic study and breast compression.
Breast ultrasound and study of nodules.
Quality control of the breast unit.
Acceptance testing of a unit or validation of a new protocol.
Training radiographers and residents without exposing any patient.

Catalogue

Features and what's included

What the equipment does and what comes in the box, as described by the manufacturer.

Features

Imaging response equivalent to human tissue in X-ray, CT and MRI.
Differentiated internal anatomy, not a homogeneous block.
No ferromagnetic components: it can enter the MRI room.
It can be scanned as often as needed and exposes nobody to radiation.

Includes

User Manual/Assembly Instructions
2-Year Warranty & Unlimited Customer Service
Weight: 11 Lbs (approx.)
Size: 32 x 23 x 13 Inches

Technical

Services for this equipment

Services matter: the equipment gets commissioned, the staff know how to use it and maintenance is settled before you start. Include them in your budget and avoid having to raise a second purchase.
